Aluminum Material Cutting Machine
Fully Automatic Aluminum Material Cutting Machine
Performance Features:
1.Low-voltage electrical control, with all the hydrauliccomponents imported from overseas market.
2.Adjustable to make different bending angles, saving thetime it takes to handle the work-piece.
3.Measures are taken with the lower cylinder for pressureregulation and holding, so as to ensure wrinkle-free bendingThe total pressure and the protection pressure are separatelyset and displayed.
Applicable Scope:
- Chairs
- Sports Equipment
- Furniture In General
- Mass Productionof Strollers
Semi-Automatic Aluminum Material Cutting Machine
Performance Features:
1.The hidden saw-blade means enhanced safety and better performance.
2.The treadle-type switch allows automatic swaging and sawing.
3.Automatic oil injection leaves no burrs on the cut surface: therefore, the saw blade is more durable.
4.Sawing of a single piece and simultaneously of mutiple pieces are both possible, henceapplicable for production at both a small and a large amount.
Applicable Scope:
- Chairs
- Sports Equipment
- Furniture In General
- Mass Productionof Strollers
Main Technical Parameter
| Cutting angle | 90° & 45° |
| Maximum cutting width | 300mm |
| Maximum cutting thickness | 125mm |
| Speed of the Spindle | 3500RPM |
| Saw-blade size | Φ455xΦ25.4 |
| Cutting speed | 10-15cycle/min |
| Area of the Work Surface | 645x688mm |
| Height of the work ground | 850mm |
| Motor | 3kwx2 pole |
| Air pressure required | 5-6kw/cm² |
| Length of the Feeding Rack | Can be customized according to your company's needs |
| Dimension | 840mm |
| Packing size | 890x740x1350mm |
| Weight | 303kg |
